ST50370
Part delivery is possible
If the desired amount is not shown as in stock, we can make a part delivery. We will contact you as soon as possible with the expected delivery date on the outstanding part of your order.
If you would like a quotation for other amounts, please contact us. [email protected]
Subject to goods being unsold. Stock levels are updated continuously round the clock.
| Dh - Min. hole (mm) | 9.53 |
|---|---|
| Dd - Max shaft (mm) | 4.75 |
| L0 - Unloaded length (mm) | 31.75 |
| R - Spring constant (N/mm) | 25.60 |
| S1 - Travel at F1 (mm) | 4.76 |
| L1 - Length at F1 (mm) | 26.99 |
| F1 - Force in N at S1 (N) | 122.00 |
| Sn - Maximum travel (mm) | 7.30 |
| Ln - Max. loaded length (mm) | 24.45 |
| Fn - Maximum load at Ln (N) | 187.00 |
